CCTV Conduit Inspections

We have the ability to camera sewer, stormwater and other pipelines and conduits from 100mm through to 2 meters, and above. CCTV Float Surveys for charged pipes and walk through inspections also available. We regularly perform council SW acceptance surveys for plumbers and civil contractors, water authority sewer dilapidation surveys for construction contractors and general pipeline investigation surveys.

Please contact Geoff if you require more detailed specifications than those listed below.

CCTV Tractor Camera

DrainJet use the Mini-Cam Proteus Mainline system. We have a 140 and a 300 crawler and extension kit, both with motorised elevator, this allows us to centralise in a 150mm reline through to a 2.2m conduit. Camera is full pan, rotate and zoom with lasers for crack measurement. Cable drum is 500m fully automatic, we also have a 250m easement reel with a 100m link cable. Laser profiling and inclination reporting also available.

All surveys are completed in Wincan VX to WSA 05 2008 or 2013 and all operators hold the qualification NWPNET016 - Inspect Sewer or Stormwater Line. Geoff the business owner also holds the qulification NWPNET017 - Supervise and Report on Conduit Inspections.

CCTV Pushrod Camera

We have two Ridgid Seesnake 325' Pushrod drain cameras. Pushrod has self-levelling head and is capable of surveying pipelines from 100 mm up to 150 mm. We are also able to locate the camera head with our locator and provide a CCTV report done in the Ridgid SeeSnake software on a USB stick on  completion.
